Main Unit
Channels | 2.1 |
Power Output | 100 W per Channel @ 8 Ohms, 20 Hz to 20 kHz, 0.08% THD, 2 Channels Driven 120 W per Channel @ 6 Ohms, 1 kHz, 0.7% THD, 2 Channels Driven 175 W @ 6 Ohms, 1 kHz, 10% THD, 1 Channel Driven |
Speaker Impedance | A or B: 4 to 16 Ohms A and B: 8 to 16 Ohms |
Files Supported | MP3, WMA, AAC, DSD (2.8/5.6 MHz), FLAC, ALAC, and WAV |
Tuner
Tuner Type | AM & FM |
Reception Frequencies | FM: 87.5 to 107.9 MHz AM: 520 to 1710 kHz |
Video
Pass-Through | 4K, ALLM (Auto Low-Latency Mode) CEC, eARC, 3D |
HDR Support | HDR10, HLG |
HDCP Compliance | 2.3 |
Connectivity
Wi-Fi | Yes |
Bluetooth | Yes |
Inputs | 5 x HDMI 3 x Gold-Plated Stereo RCA (1 Phono MM with Ground Screw) 2 x Optical TOSLINK 1 x Digital Coaxial |
Outputs | 1 x HDMI 2 x Gold-Plated RCA Subwoofer Pre-Outs 1 x Gold-Plated Stereo RCA Zone 2 Pre-Out 1 x 1/4″ / 6.35 mm Headphone (Front) |
Other Connections | 1 x USB Type-A (Front) 1 x RJ45 Ethernet LAN 1 x AM Antenna 1 x FM Antenna 1 x 1/8″ / 3.5 mm IR Remote Control In |
Speaker Connectors | 4 x Gold-Plated Binding Post Pairs (A/B) |
A/B Speaker Selection | A, B, A and B |
Physical Specifications
Power Requirements | 120 VAC, 60 Hz |
Standby Power Consumption | 0.1 W CEC Standby: 0.5 W |
Dimensions | 43.4 x 15.1 x 33.9 cm with Antennas Horizontal 43.4 x 21.5 x 33.9 cm with Antennas Vertical |
Weight | 8.3 kg |
