All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter.
- Continuous output power into 8 ohms and 4 ohms: >80 W (ref. 20 Hz-20 kHz at rated THD+N, both channels driven); >100 W
- THD+N (20 Hz – 20 kHz) at rated power: <0.04 %
- Signal-to-Noise Ratio: >84 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)
- Clipping power: >86 W (at 1 kHz 8 ohms 0.1 % THD), >102 W (at 1 kHz 4 ohms 0.1 % THD)
- IHF dynamic power: 8 ohms: 100 W, 4 ohms: 125 W
- Damping factor: >90 (ref. 8 ohms, 20Hz to 20kHz)
- Frequency response: ±0.18 dB (20 Hz – 20 kHz)
- Tone controls: Treble: ±6.0 dB at 20 kHz, Bass: ±6.0dB at 60 Hz
- Channel separation >93 dB (1 kHz), >72 dB (10 kHz)
- Input sensitivity (for 80 W in 8 ohms): Line In: 550 mV, Digital In: -12 %FS
- Trigger Out: 12 ± 1 V, 9 mA
- Standby power: >0.5W
SUBWOOFER OUT
- Maximum output level: 4.0 Vrms (ref 0.0032% THD+N 100 Hz)
- Signal-to-Noise ratio: >106 dB (20 Hz-20 kHz, ref 1V out)
- THD+N: >0.006 % (20 Hz-200 Hz, ref 1.964V)
- Output impedance: 600 ohms
BluOS SECTION
AUDIO
- toetatud audioformaadid: https://support.bluos.net/hc/en-us/articles/360000191327-What-Formats-are-Supported-by-BluOS
- samplingusagedus: kuni 32 bit/192 kHz PCM
- biti sügavus: 16 – 24
CONNECTIVITY
- Network connectivity: Gigabit Ethernet RJ45 Wi-Fi 5
- USB: 1 x Type-A port for connection to USB memory stick (FAT32 or NTFS formatted) and supported peripherals
- Bluetooth quality: aptX HD
- Bluetooth connectivity: Two-Way (Receive and Headphone modes)
USER INTERFACE
- Supported operating system: Music playback from network shares on the following desktop operating systems: Microsoft Windows XP, 2000, Vista, 7, 8 to current Windows Operating Systems and macOS versions
- Mobile Application: Free BluOS Controller App available for download from the respective App stores of Apple iOS devices (iPad, iPhone and iPod), Android devices, Kindle Fire and Windows or macOS desktops
- Front panel: Combination of front panel control knob and buttons
SUPPORTED SERVICES
- Supported Radio, Music Services, Integration and Digital Assistants: https://support.bluos.net/hc/en-us/articles/360000191327-What-Formats-are-Supported-by-BluOS
DIMENSION AND WEIGHT
- mõõtmed (W x H x D): 218 x 96 x 266 mm
- kaal: 4.8 kg
